SPECIFICATIONS
Applicable Material: Metal, Aluminum, Plastic, Polyester, Polyvinyl Chloride, Vinyl, Wood
Brand Name: NoEnName_Null
Expand IO: 4 inputs/4 outputs
Heating Element: nichrome
High-concerned chemical: None
Material: Stainless Steel
Maximum speed (MM/S): 500
Operating system: LCD panel/hand-held programmer
Origin: Mainland China
Plug Type: European Plug
Program storage capacity: 999 parameter files (65,535 points per file)
Repetitive round-trip accuracy (MM): ±0.02MM-0.05MM
Sport mode: 3 Axis point-to-point, continuous straight line
Transmission mode: Taiwan Shangyin guide rail (slider)
Type: Other
Work environment: Humidity: 20-90% ℃, temperature: 0-40 ℃
Working range X/Y/Z (MM): Model can be customized
brand name: xiaomao
condition: New
current: 110V~220V
dimensions: 500*300*300*100
place of origin: Guangdong, China
rated capacity: 1000 W
type: Automatic Solders
usage: Industrial
voltage: 110V~220V
warranty: 1 Year
weight (kg): 68
My friend, welcome to our store, if you need other models of this product, please contact me, I will send the product link for you to buy! If you have any questions, please feel free to contact me. Please contact me to get more details and discounts: E-mail: 1761780895@qq.com Whatsapp : +86-18045004476 Wechat: +86 18045004476
|
Main configuration:
|
|
|
|
|
name
|
unit
|
quantity
|
remarks
|
|
Motor
|
set
|
4
|
Rexay/Gemicon/Best
|
|
drive
|
set
|
4
|
Nippon Shinano/Best/Jermykon
|
|
Temperature control and heating core
|
set
|
1
|
Weller
|
|
Temperature Range
|
℃
|
|
0-500℃
|
|
a sensor
|
piece
|
4
|
Japan
|
|
Power Supply
|
set
|
1
|
Mingwei, Taiwan
|
|
Automatic soldering machine system
|
set
|
1
|
Full time/Yuntu
|
Product features:
◎ Precision temperature controller, fast temperature difference compensation; ◎ Imported heating element from Germany WELLER, with uniform and stable temperature ◎ Program optimization, simple operation and teaching programming ◎ High precision tin feeding mechanism, without blocking tin, with tin breaking function. ◎ It can be equipped with the function of rotary soldering, supporting spot welding and drag welding ◎ The automatic soldering machine can deliver tin more accurately, and there is no tin explosion during soldering; ◎ The automatic soldering machine has the functions of spot welding, oblique welding, buffeting welding, etc. ◎ The soldering tin control system adopts the world's leading motion control card, which is more user-friendly than PLC programming. The working program of the equipment can be copied point to point and block to block, reducing the time for program writing. ◎ The automatic soldering machine has the function of automatically clearing the soldering head, which can improve the efficiency of soldering to a certain extent.
1.How to guarantee the quality of your products? 1) Strict detection during production. 2) Before shipment, the products shall be strictly checked, and after debugging, the products shall be packaged and shipped to ensure that there are no problems. 2. What is your terms of payment？ T/T 50% as deposit, and 50% before delivery. We will show you the photos of the products and packages before you pay the balance. 3. May I buy samples from you? Yes! You are welcome to place sample order to test our superior quality and service. Sample's price is the same as bulk's price. Or you can send us samples of your product and we test it on machine. Video for you to make samples. 4. How to operate the equipment? We have made video for you to show you how to do it step by step. Contact our engineers at any time when you don’t understand, support video and telephone communication. 5. Do you have any After-Sales service? Yes! The Engineer is online for 24-hours, they can check the problems and then give you solution way very soon. Please rest assured that manual will be offered along with machine, ensuring you can operate the machine easily. 6. Are you just trading company or factory? We are professional manufacturer for automation machine since 2017. Our factory is located in Longgang District, Shenzhen City,Guangdong Province. Welcome you to visit our factory.
